The 9GT0624P4G001 is a DC axial cooling fan from Sanyo Denki’s San Ace 60T wide-temperature series, sized 60×60×25 mm with a rated voltage of 24V DC. Developed for industrial electronics exposed to extreme cold and high heat, this fan delivers consistent, reliable cooling performance across an ultra-wide operating temperature window of -40°C to +85°C, outperforming standard fans that cannot withstand harsh fluctuating ambient conditions.
It features a durable aluminum frame paired with UL94V-1 flame-retardant plastic impeller, fully certified to UL, CSA, EN safety standards and compliant with RoHS environmental directives for global export projects. Built-in dual motor protection circuits—locked rotor burnout protection and reverse polarity protection—eliminate permanent motor damage caused by wiring errors or impeller stall. Equipped with industry-standard 25kHz PWM speed regulation and a pulse tachometer sensor, it supports intelligent closed-loop thermal control for new energy inverters, refrigeration hardware, communications enclosures and high-temperature lighting systems.
Full Technical Specifications
-
Model Number: 9GT0624P4G001
-
Overall Dimension: 60 × 60 × 25 mm
-
Frame Material: Aluminum
-
Rated Voltage: 24 V DC
-
Operating Voltage Range: 20.4 ~ 27.6 V
-
Rated Current: 0.28 A
-
Rated Input Power: 6.72 W
-
Rated Rotational Speed: 10000 min⁻¹
-
Maximum Airflow: 1.26 m³/min (44.5 CFM)
-
Maximum Static Pressure: 243 Pa (0.97 inchH₂O)
-
Sound Pressure Level: 52 dB(A), measured 1 meter from fan air inlet
-
Operating Temperature: -40°C ~ +85°C
-
Storage Temperature: -40°C ~ +85°C (Non-condensing environment)
-
L10 Expected Service Life: 40,000 hours continuous running at 85℃ free air; 162,000 hours at 40℃ (90% product survival rate)
-
Net Weight: 100 g
-
Control Function: 25kHz PWM speed control supported
-
Sensor Type: Pulse tachometer sensor
-
Ribbed Frame: No
-
Certifications: UL ratings, CSA standards, EN standards, RoHS Compliant
Core Product Advantages
-
Ultra-Wide Extreme Temperature Operation
Stable continuous operation from -40°C freezing low temperature up to 85°C high temperature. It solves thermal management challenges for industrial freezers, high-power LED lighting, outdoor power supplies and PV inverters that regular cooling fans fail to handle.
-
Extended L10 Lifespan to Cut System Maintenance Costs
It reaches 40,000 hours L10 service life under sustained 85°C high-temperature operation. Longer fan service life reduces equipment downtime, replacement frequency and the total cost of ownership (TCO) of your industrial thermal systems.
-
PWM Speed Modulation with Real-Time Rotational Feedback
Supports 25kHz PWM duty cycle speed adjustment to dynamically match airflow output to real-time equipment heat load. The integrated pulse sensor transmits live rotational speed signals, enabling real-time temperature monitoring, equipment fault alarms and automatic thermal regulation within intelligent control systems.
-
Dual Embedded Motor Safety Protection
Two independent protective circuits are integrated inside the fan motor. Locked rotor protection automatically cuts power when the impeller is blocked; reverse polarity protection prevents motor burnout if power cables are connected backwards, avoiding unexpected system shutdown and hardware failure.
-
Global Safety & Environmental Certifications for Worldwide Export
Passed UL, CSA and EN international safety standards and fully RoHS compliant. This fan satisfies regulatory compliance requirements for industrial equipment exported to North America, Europe and all global overseas markets.
Typical Application Scenarios
-
PV inverters and new energy power conversion equipment
-
Low-temperature refrigeration cabinets, industrial freezers and cold storage devices
-
High-power industrial LED & heat-generating lighting fixtures
-
Telecommunication base stations and industrial control enclosures
-
Outdoor electronic hardware exposed to extreme temperature fluctuations
-
High voltage industrial power supplies
∷
