4028 24V Splash Proof Fan

9WPA0424H30011

Brand: SanAce (Japan sanyodenki)
Size: 40x40x28mm
Characteristics: IP68 Splash Proof Fan
Signal line: 3-wire FG
Product description: Discover the San Ace 9WPA0424H30011, a 40×40×28mm IP68 splash-proof DC fan from Sanyo Denki. Delivering 18500 RPM, 0.52 m³/min airflow, and 375 Pa static pressure at 24V, this fan features a pulse sen
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
暂无	9WPA0412P3G001	12	10.8~13.2	0.5	6	22200	0.63	22.2	555		2.22	53
暂无	9WPA0412P3G0011	12	10.8~13.2	0.5	6	22200	0.63	22.2	555		2.22	53
暂无	9WPA0424P3G001	24	21.6~26.4	0.25	6	22200	0.63	22.2	555		2.22	53
暂无	9WPA0424P3G0011	24	21.6~26.4	0.25	6	22200	0.63	22.2	555		2.22	53
暂无	9WPA0412H3001	12	10.8~13.2	0.34	4.1	18500	0.52	18.3	375		1.51	48
暂无	9WPA0412H30011	12	10.8~13.2	0.34	4.1	18500	0.52	18.3	375		1.51	48
暂无	9WPA0424H3001	24	21.6~26.4	0.17	4.1	18500	0.52	18.3	375		1.51	48
	9WPA0424H30011	24	21.6~26.4	0.17	4.1	18500	0.52	18.3	375		1.51	48
暂无	9WL0412P3J001	12	10.8~13.2	0.52	6.24	17500	0.63	22.2	400		1.61	51
暂无	9WL0412P3G001	12	10.8~13.2	0.4	4.8	15500	0.56	19.7	310		1.24	47
暂无	9WL0424P3J001	24	21.6~26.4	0.26	6.24	17500	0.63	22.2	400		1.61	51
暂无	9WL0424P3G001	24	21.6~26.4	0.2	4.8	15500	0.56	19.7	310		1.24	47

PRODUCT PRESENTATION

Sanyo Denki San Ace 40W 9WPA0424H30011

IP68 Splash Proof 24V DC Cooling Fan

1. Product Overview

The San Ace 9WPA0424H30011 is a compact, high-performance Splash Proof Fan from Sanyo Denki’s renowned San Ace series. Designed to thrive in moisture-prone, dusty, and harsh environments, this 40×40×28mm DC fan features an IP68 rating, lightweight plastic construction, and industry-leading static pressure performance. It delivers reliable cooling for outdoor, industrial, and mission-critical applications, backed by Sanyo Denki’s signature long-life reliability.

2. Full Technical Specifications

表格

Parameter	Specification
Model No.	9WPA0424H30011
Series	San Ace 40W Splash Proof Fan
Frame Size (L×W×H)	40 × 40 × 28 mm
Rated Voltage	24 V DC
Operating Voltage Range	14 ~ 27.6 V DC
Rated Current	0.17 A
Rated Input Power	4.1 W
Rated Speed	18500 min⁻¹ (RPM)
Maximum Airflow	0.52 m³/min (18.3 CFM)
Maximum Static Pressure	375 Pa (1.51 inchH₂O)
Sound Pressure Level (SPL)	48 dB(A)
Operating Temperature Range	-20 ~ +70 °C (non-condensing)
Expected Lifespan	40,000 hours @ 60°C / 70,000 hours @ 40°C
Frame Material	UL 94V-0 flame-retardant plastic
IP Rating	IP68 (Dust-tight, protected against continuous water immersion)
PWM Control Function	No
Sensor Type	Pulse Sensor (Tachometer Output)
Mass	60 g
Certifications	UL, CSA, EN, RoHS Directive
Ribbed Design	No

3. Core Features & Key Advantages

✅ IP68 Splash Proof & Dust-Tight Construction

Engineered with a fully sealed enclosure, the 9WPA0424H30011 meets IP68 standards, making it resistant to water splashes, moisture, and dust ingress. This splash-proof design ensures reliable operation in rain, humidity, and dusty industrial environments.

✅ Ultra-High Static Pressure Performance

With a maximum static pressure of 375 Pa, this fan excels at moving air through dense, restricted, or filtered spaces, delivering effective cooling even in compact, high-density electronic enclosures.

✅ Lightweight & Space-Saving Design

At just 60 grams, the fan offers a lightweight solution without compromising performance, making it ideal for weight-sensitive and space-constrained applications like portable industrial equipment and compact enclosures.

✅ Pulse Sensor Tachometer Output

The built-in pulse sensor provides real-time speed monitoring, allowing users to track fan performance and detect faults in mission-critical systems, ensuring system uptime and reliability.

✅ Wide Operating Temperature Range

Operating reliably from -20°C to +70°C, the fan adapts to extreme temperature fluctuations, making it suitable for both cold outdoor installations and high-temperature industrial environments.

✅ Global Compliance & Certifications

The fan meets international safety and environmental standards, including UL, CSA, EN, and RoHS, ensuring compatibility with global regulatory requirements for industrial and commercial applications.

4. Typical Applications

The San Ace 9WPA0424H30011 is ideal for cooling applications requiring splash-proof and high-static pressure performance:

Outdoor digital signage and kiosks
EV charging stations and power inverters
Industrial automation and control equipment
Renewable energy systems (solar/wind inverters)
Telecommunications base stations
Harsh-environment electronic enclosures
Dusty factory automation equipment

5. Compliance & Certifications

The 9WPA0424H30011 complies with the following global standards:

UL Safety Ratings
CSA Standards
EN Standards
RoHS Directive (Restriction of Hazardous Substances)
